In the field of conventional cargo transportation, box trailers play an extremely important role. In long-distance transportation, it connects different cities and regions, allowing goods to flow smoothly between production and consumption areas, and effectively promoting regional trade exchanges. In urban logistics distribution, it is responsible for accurately distributing goods from large logistics centers to various retail outlets, distribution stations, or enterprise warehouses to meet the daily supply of materials in the city.
Box trailers also have the function of temporary storage and operation platforms. When faced with the need for temporary storage of goods, whether in logistics parks or construction sites, it can be temporarily parked and transformed into a temporary storage space to meet short-term storage needs of goods. In special work scenarios such as road construction, bridge construction, and power repair, it can also serve as a mobile work platform, providing a workspace for construction personnel and facilitating the storage of various construction tools and equipment, significantly improving work efficiency.
| Product Name: | Van Semi Trailer/Trailer van/Box Semi Trailer |
| Dimension: | 10000-13000*2550*3400 mm |
| Payload: | 60,000 kgs |
| Main beam: | Material Q345. Fabricated “H” beam height 500mm, Top flange thickness 14mm, |
| Middle web thickness 8mm, Bottom flange thickness 16mm | |
| Side beam: | 16# channel steel |
| Platform: | 3mm thick checkered plate. |
| Side walls: | 600-1800 mm height. |
| Kingpin: | JOST 2” Kingpin, bolted in type |
| Welding standard: | All welding are to be done by qualified welder per applicable national standard |
| Painting: | Complete Chassis sand blasting to clean rust, 1 coat of anti corrosive primer, |
| Suspension: | Leaf spring or Air suspension |
| Axle: | FUWA/BPW 13 tons axles |
| Brake system: | Dual line pneumatic brake, with hose and connector |
| Brake chamber: | 6 units T30/30 spring brake chambers |
| Air tank: | 40L, 2 pcs, China |
| Emergency | WABCO/Shunanda relay valve |
| relay valve: | |
| Tire: | 12R22.5, 12 pcs. |
| Landing gear: | Standard 28T two speed telescopic manual landing gear |
| Electrical | Voltage:24V Receptacle: 7 ways (7 wire harness) |
| A full set of LED lights installed on the trailer, front rear side turning etc. | |
| Spare wheel carrier | Two sets of spare wheel carrier |
| Accessory | One tooling box with a set of standard trailer tool |
